1047(w)x2050(h)x10mm Glass Shower Screen Return/Fixed Panel

This panel can be used as a return panel when installing a corner shower or a fixed panel when installing a single panel screen.

• Width: 1047mm
• Height: 2050mm
• Thickness: 10mm
• Weight: 54kg
• Allow a 3mm Gap between the wall and glass and a 3mm Gap between this panel and the door.

Installation Widths:

• 1050mm when installing with a wall bracket
• 1057-1060mm when installing with 19mm U Channel
• 1057-1072mm when installing with 35mm U Channel

Round D Chrome Shower Screen Door Handle

• Round D Handle Shower Screen Door Handle
• Stainless steel in a mirror finish
• Pull Knob on inside of Door Panel and D Handle on the outside
• Suits 8mm, 10mm and 12mm thick glass
• Requires 2 x 12mm holes at 155mm centres
• Nylon spacers and gaskets included to prevent glass/metal contact

Polaris 125 Series Glass/Wall Hinges

The Polaris Soft Close Hinge is a state-of-the-art product unrivaled in design, style and safety

The Polaris soft close hinge is the safest and most reliable specially designed pool fence hinge in the industry that complies with the stringent Australian Standards AS1926 and AS 2820.

• New and improved 125 series hinge is now made with duplex SS2205 stainless steel
• Improved design features including commercial rated adjustable tension spring (tempered SS304) with multiple spring closing settings (soft, medium & strong) and the highest quality
• European made dampeners for smooth, soft close action
• Self closing hinge suitable for 10mm and 12mm thick glass gates
• Revolutionary anti-drop gate packing system significantly lowers the chance of gates dropping or sagging over time
• Easy installation process – install guide included in each box
• Available in polish, satin, matt black and matt white finishes

50mm Diameter x 30mm Body Standoff for Face Mount Glass Balustrade / Pool Fence

• 50mm Diameter
• 30mm High Body
• Requires a 20-22mm Diameter hole in the glass
• Install using M12 Threaded Rod into masonry
• Install using M12 Metric to Lag Screw into timber
• Kit includes: Cap, Body, 2 x Plastic Washers and 1 x Bush
• For Face Mount Glass Balustrade / Pool Fence

M12 Fixing rods sold separately

1097(w)x2050(h)x10mm Glass Shower Screen Return/Fixed Panel

This panel can be used as a return panel when installing a corner shower or a fixed panel when installing a single panel screen.

• Width: 1097mm
• Height: 2050mm
• Thickness: 10mm
• Weight: 57kg
• Allow a 3mm Gap between the wall and glass and a 3mm Gap between this panel and the door.

Installation Widths:

• 1100mm when installing with a wall bracket
• 1107-1110mm when installing with 19mm U Channel
• 1107-1122mm when installing with 35mm U Channel

Small Glass Brace Bracket - Chrome Plated - For Shower Screen

Used to stiffen and brace a return or hinge panel by fixing a brace panel along the top and tying them together.

Can also be used to tie a Fixed panel back to the wall.

• Small Glass Brace Bracket
• Square Finish Edges
• Brace 8mm thick glass hood to 10mm thick return & hinge panels
• 2 x compression/friction screws
• Slimline Design
• No holes required in glass
• Made from solid brass

Tip: Place bracket ensuring glass door does not hit when swinging inwards.

50mm Diameter x 50mm Body Standoff for Face Mount Glass Balustrade / Pool Fence

• 50mm Diameter
• 50mm High Body
• Requires a 20-22mm Diameter hole in the glass
• Install using M12 Threaded Rod into masonry
• Install using M12 Metric to Lag Screw into timber
• Kit includes: Cap, Body, 2 x Plastic Washers and 1 x Bush
• For Face Mount Glass Balustrade / Pool Fence

M12 Fixing sold separately

1147(w)x2050(h)x10mm Glass Shower Screen Return/Fixed Panel

This panel can be used as a return panel when installing a corner shower or a fixed panel when installing a single panel screen.

• Width: 1147mm
• Height: 2050mm
• Thickness: 10mm
• Weight: 59kg
• Allow a 3mm Gap between the wall and glass and a 3mm Gap between this panel and the door.

Installation Widths:

• 1150mm when installing with a wall bracket
• 1157-1160mm when installing with 19mm U Channel
• 1157-1172mm when installing with 35mm U Channel

40mm Square Cap x 30mm Body Standoff for Face Mount Glass Balustrade / Pool Fence

• 40mm Square Cap
• 30mm High Body
• Requires a 20-22mm Diameter hole in the glass
• Install using M12 Threaded Rod for Masonry
• Install using M12 Metric to Lag Screw for timber
• Kit includes: Cap, Body, 2 x Plastic Washers and 1 x Bush
• For Face Mount Glass Balustrade / Pool Fence

M12 Fixing rods sold separately

1197(w)x2050(h)x10mm Glass Shower Screen Return/Fixed Panel

This panel can be used as a return panel when installing a corner shower or a fixed panel when installing a single panel screen.

• Width: 1197mm
• Height: 2050mm
• Thickness: 10mm
• Weight: 61kg
• Allow a 3mm Gap between the wall and glass and a 3mm Gap between this panel and the door.

Installation Widths:

• 1200mm when installing with a wall bracket
• 1207-1210mm when installing with 19mm U Channel
• 1207-1222mm when installing with 35mm U Channel

Large Glass Brace Bracket - Chrome Plated - For Shower Screen

Used to stiffen and brace a return or hinge panel by fixing a brace panel along the top and tying them together.

Can also be used to tie a Fixed panel back to the wall.

• Small Glass Brace Bracket
• Square Finish Edges
• Brace 8mm thick glass hood to 10mm thick return & hinge panels
• 4 x compression/friction screws
• Sturdy design
• No holes required in glass
• Made from solid brass

Tip: Place bracket ensuring glass door does not hit when swinging inwards.

Slimline Round Chrome Shower Screen Door Knob

• Slimline 25mm Diameter Round Knob for Glass Shower Screen Door
• Chrome Plated Finish
• Double pull knob
• Suits 6mm, 8mm, 10mm and 12mm thick glass
• Requires a 12mm hole in the door
• Made from Solid Brass
• Nylon spacers and gaskets included to prevent glass/metal contact

115mm Lag Screw to Metric Thread

• M12 Heavy Duty Screw
• 115mm overall length
• Allows installation into timber or composite material
• Suits all standoffs
• Hex drive allen head.

1297(w)x2050(h)x10mm Glass Shower Screen Return/Fixed Panel

This panel can be used as a return panel when installing a corner shower or a fixed panel when installing a single panel screen.

• Width: 1297mm
• Height: 2050mm
• Thickness: 10mm
• Weight: 67kg
• Allow a 3mm Gap between the wall and glass and a 3mm Gap between this panel and the door.

Installation Widths:

• 1300mm when installing with a wall bracket
• 1307-1310mm when installing with 19mm U Channel
• 1307-1322mm when installing with 35mm U Channel

160mm Lag Screw to Metric Thread

• M12 Heavy Duty Screw
• 160mm overall length
• Allows installation into timber or composite material
• Suits all standoffs
• Hex drive allen head.

1397(w)x2050(h)x10mm Glass Shower Screen Return/Fixed Panel

This panel can be used as a return panel when installing a corner shower or a fixed panel when installing a single panel screen.

• Width: 1397mm
• Height: 2050mm
• Thickness: 10mm
• Weight: 72kg
• Allow a 3mm Gap between the wall and glass and a 3mm Gap between this panel and the door.

Installation Widths:

• 1400mm when installing with a wall bracket
• 1407-1410mm when installing with 19mm U Channel
• 1407-1422mm when installing with 35mm U Channel

Glass to Back Wall Brace Bracket - Chrome Plated - For Shower Screen

Used to stiffen and brace a Return/Fixed panel by tying it to the wall.

• Back Wall to Glass support arm
• Double adjustability for easy installation. Adjustable at wall & at glass
• Hidden fixing wall installation for a neat finish.
• Suitable for 8 and 10mm thick glass
• Compression/friction screws secure to the glass. No holes in glass required
• Made from Brass

M12 x 120mm Threaded Rod

• M12 Heavy Duty
• 120mm overall length
• Allows installation into concrete by using a chemical anchor
• Allows installation through steel using an M12 nut or tapped thread
• Suits all standoffs

Round Glass to Wall Adjustable Horizontal Support Arm - Chrome Plated - For Shower Screen

Used to stiffen and brace a Return/Fixed panel by connecting it to the adjacent wall.

• Adjacent Wall to Glass support arm
• Adjustable length by cutting the tube to the required length.
• Maximum width of 1200mm
• Hidden fixing wall installation for a neat finish.
• Suitable for 8 and 10mm thick glass
• Compression/friction screws secure to the glass. No holes in glass required
• Made from Brass with Stainless Steel Tube

M12 x 1000mm Threaded Rod

• M12 Heavy Duty
• 1000mm overall length
• Allows installation into concrete by using a chemical anchor
• Allows installation through steel using an M12 nut or tapped thread
• Suits all standoffs

35mm Deep 2100mm Long Chrome Shower Screen Aluminium U Channel

• 35mm Deep Anodised Aluminium Channel
• Adds 10mm to 25mm to the overall glass width
• High Polished Chrome Look Finish
• Dry Glaze System - No need for silicon in glass
• Suits 10mm Glass
• Consider using where the wall is out of square (up to 15mm) or where a slimline channel looks is desired
• Unique Aluminium extrusion has internal ribs which hold secure 2part Clear Glazing PVC
• Fast Installation
• U-Channel & 2 Part Glazing PVC Included

Standoff Tool

• Tighten and loosen 38mm and 50mm diameter standoffs
• Made from 316 Stainless Steel

Glass to Ceiling Adjustable Brace Bracket - Chrome Plated - For Shower Screen

Used to stiffen and brace a Return/Fixed panel by tying it to the ceiling.

• Ceiling to Glass support arm
• Adjustable length by cutting the tube to the required length.
• Hidden fixing wall installation for a neat finish.
• Suitable for 8 and 10mm thick glass
• Compression/friction screws secure to the glass. No holes in glass required
• Made from Brass with Stainless Steel Tube

50mm Diameter Round Offset Fixed Bracket - Suits round and Flat Rails

• 50mm Diameter Round Cap
• Suits round or flat rails
• Includes 3 Saddles 38mm, 50mm and Flat. You can simply change the saddle to use with different profile handrails.
• Requires a 20mm Diameter Hole in the Glass

Square L Shape Chrome Shower Screen Door Knob

• Square L Shape Knob for Shower Screen Door
• Chrome Plate Finish
• Double pull knob
• Suits 8mm, 10mm and 12mm thick glass
• Requires a 12mm hole in the door
• Made from Solid Brass
• Nylon spacers and gaskets included to prevent glass/metal contact

Square Recessed Chrome Shower Screen Door Knob

• Square Recessed Shape Knob for Shower Screen Door
• Chrome Plated Finish
• Double pull knob
• Suits 8mm, 10mm and 12mm thick glass
• Requires a 12mm hole in the door
• Made from Solid Brass
• Nylon spacers and gaskets included to prevent glass/metal contact

Round Chrome Shower Screen Door Knob

• Round with finger notch Knob for Glass Shower Screen Door
• Chrome Plated Finish
• Double pull knob
• Suits 8mm, 10mm and 12mm thick glass
• Requires a 12mm hole in the door
• Made from Solid Brass
• Nylon spacers and gaskets included to prevent glass/metal contact

Round Recessed Chrome Shower Screen Door Knob

• Round Recessed Knob for Glass Shower Screen Door
• Chrome Plated
• Double pull knob
• Suits 8mm, 10mm and 12mm thick glass
• Requires a 12mm hole in the door
• Made from Solid Brass
• Nylon spacers and gaskets included to prevent glass/metal contact
