Polished Stainless Polaris 125 Series Glass/Wall Hinges with Round Post Adapter Plate

Includes Hinges + 50mm Round Post Adapter

• Polished Stainless Steel Finish
• 2205 grade stainless steel
• 4x fixing holes to wall/post
• Self closing pool fence compliant safety hinge
• Tested to cycle count Australian Standards requirements
• Adjustable closing speed with European dampeners providing a soft close action
• Polymer cone cap supplied and can be fitted on bottom hinge for anti-toe hold
• Suits 10 or 12mm thick glass gates (max 45kg)
• Easy gate installation: firstly, fit hinges to gate and place gate in proposed position. Once in correct position, screw off to wall/post through 2 x outer holes. Then open the gate and screw off through 2 x inner holes.

Note: You will need to use a Deluxe Soft Close Glass to Wall Gate Panel with these hinges. The cut out in the glass needs to match the cut out specified for these hinges.

Satin Stainless Polaris 125 Series Glass/Wall Hinges with Round Post Adapter Plate

Includes Hinges + 50mm Round Post Adapter

• Satin Stainless Steel Finish
• 2205 grade stainless steel
• 4x fixing holes to wall/post
• Self closing pool fence compliant safety hinge
• Tested to cycle count Australian Standards requirements
• Adjustable closing speed with European dampeners providing a soft close action
• Polymer cone cap supplied and can be fitted on bottom hinge for anti-toe hold
• Suits 10 or 12mm thick glass gates (max 45kg)
• Easy gate installation: firstly, fit hinges to gate and place gate in proposed position. Once in correct position, screw off to wall/post through 2 x outer holes. Then open the gate and screw off through 2 x inner holes.

Note: You will need to use a Deluxe Soft Close Glass to Wall Gate Panel with these hinges. The cut out in the glass needs to match the cut out specified for these hinges.

Satin Stainless Polaris 125 Series Glass/Wall Hinges with Square Post Adapter Plate

Includes Hinges + 50mm Square Post Adapter

• Satin Stainless Steel Finish
• 2205 grade stainless steel
• 4x fixing holes to wall/post
• Self closing pool fence compliant safety hinge
• Tested to cycle count Australian Standards requirements
• Adjustable closing speed with European dampeners providing a soft close action
• Polymer cone cap supplied and can be fitted on bottom hinge for anti-toe hold
• Suits 10 or 12mm thick glass gates (max 45kg)
• Easy gate installation: firstly, fit hinges to gate and place gate in proposed position. Once in correct position, screw off to wall/post through 2 x outer holes. Then open the gate and screw off through 2 x inner holes.

Note: You will need to use a Deluxe Soft Close Glass to Wall Gate Panel with these hinges. The cut out in the glass needs to match the cut out specified for these hinges.

1200mm Premium Soft Close Hinge Panels

1200mm High Premium Soft Close Hinge Panel

Available in 11 sizes ranging from 600mm to 1800mm wide.

Suits Polaris 125 Series and Atlantic Soft Close Hinges

600 x 1200mm Premium Soft Close Hinge Panels

Premium Soft Close Glass Gate Hinge Panel. Used to swing a glass gate off.

• Width: 600mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 22kg
• Cutouts: 2 x Cutouts to suit premium soft close hinges

Glass is certified to Australian Standards

Note: This panel will need to be secured to a post or another glass panel using Glass Braces or Glass Clamps. It will not hole a gate if only supported by Spigots.

800 x 1200mm Premium Soft Close Hinge Panels

Premium Soft Close Glass Gate Hinge Panel. Used to swing a glass gate off.

• Width: 800mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 29kg
• Cutouts: 2 x Cutouts to suit premium soft close hinges

Glass is certified to Australian Standards

Note: This panel will need to be secured to a post or another glass panel using Glass Braces or Glass Clamps. It will not hole a gate if only supported by Spigots.

1000 x 1200mm Premium Soft Close Hinge Panels

Premium Soft Close Glass Gate Hinge Panel. Used to swing a glass gate off.

• Width: 1000mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 36kg
• Cutouts: 2 x Cutouts to suit premium soft close hinges

Glass is certified to Australian Standards

1100 x 1200mm Premium Soft Close Hinge Panels

Premium Soft Close Glass Gate Hinge Panel. Used to swing a glass gate off.

• Width: 1100mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 40kg
• Cutouts: 2 x Cutouts to suit premium soft close hinges

Glass is certified to Australian Standards

1200 x 1200mm Premium Soft Close Hinge Panels

Premium Soft Close Glass Gate Hinge Panel. Used to swing a glass gate off.

• Width: 1200mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 43kg
• Cutouts: 2 x Cutouts to suit premium soft close hinges

Glass is certified to Australian Standards

1300 x 1200mm Premium Soft Close Hinge Panels

Premium Soft Close Glass Gate Hinge Panel. Used to swing a glass gate off.

• Width: 1300mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 47kg
• Cutouts: 2 x Cutouts to suit premium soft close hinges

Glass is certified to Australian Standards

1400 x 1200mm Premium Soft Close Hinge Panels

Premium Soft Close Glass Gate Hinge Panel. Used to swing a glass gate off.

• Width: 1400mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 50kg
• Cutouts: 2 x Cutouts to suit premium soft close hinges

Glass is certified to Australian Standards

1500 x 1200mm Premium Soft Close Hinge Panels

Premium Soft Close Glass Gate Hinge Panel. Used to swing a glass gate off.

• Width: 1500mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 54kg
• Cutouts: 2 x Cutouts to suit premium soft close hinges

Glass is certified to Australian Standards

1600 x 1200mm Premium Soft Close Hinge Panels

Premium Soft Close Glass Gate Hinge Panel. Used to swing a glass gate off.

• Width: 1600mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 58kg
• Cutouts: 2 x Cutouts to suit premium soft close hinges

Glass is certified to Australian Standards

1700 x 1200mm Premium Soft Close Hinge Panels

Premium Soft Close Glass Gate Hinge Panel. Used to swing a glass gate off.

• Width: 1700mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 61kg
• Cutouts: 2 x Cutouts to suit premium soft close hinges

Glass is certified to Australian Standards

1800 x 1200mm Premium Soft Close Hinge Panels

Premium Soft Close Glass Gate Hinge Panel. Used to swing a glass gate off.

• Width: 1800mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 65kg
• Cutouts: 2 x Cutouts to suit premium soft close hinges

Glass is certified to Australian Standards

1200mm Premium Soft Close Gate Panel

1200mm 12mm Thick Premium Soft Close Gate Panels

Available in 800mm and 900mm wide.

There are two options available

• Glass to Glass
• Glass to Wall/Post

You will need to order the matching hinges as the cutouts in the glass are different sizes on the 2 panels.

800 x 1200 x 12mm Glass/Glass Soft Close Gate Panel

• 800mm wide x 1200mm high frameless gate
• 12mm Grade A toughened safety glass
• Glass-to-Glass layout
• Soft close hinges (sold separately) for smooth, quiet closing
• Polished, high-quality glass edges
• Complies with Australian Pool Fencing Standard AS1926.1
• Ideal for pool fencing and outdoor areas
• Easy to install with soft close hinges and latch (not included)

Polished Stainless Glass to Glass Spring Hinge

• Glass to Glass Gate Hinge
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Suits 8 & 10mm Glass Gates
• Suits 12mm Hinge Panel
• 316 Grade Stainless
• Gate needs to be drilled with 4 x 10mm Holes (24mm in from the side and 47 apart)
• Hinge panel needs to be drilled 4 x 14mm Holes (40mm in from the side and 60mm apart)
• For best results allow for a 10mm gap between the hinge panel and gate

Satin Stainless Glass to Glass Spring Hinge

• Glass to Glass Gate Hinge
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Suits 8 & 10mm Glass Gates
• Suits 12mm Hinge Panel
• 316 Grade Stainless
• Gate needs to be drilled with 4 x 10mm Holes (24mm in from the side and 47 apart)
• Hinge panel needs to be drilled 4 x 14mm Holes (40mm in from the side and 60mm apart)
• For best results allow for a 10mm gap between the hinge panel and gate

Matt Black Glass to Glass Spring Hinge

• Matt Black Glass to Glass Gate Hinge
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Suits 8 & 10mm Glass Gates
• Suits 12mm Hinge Panel
• 316 Grade Stainless powder coated backing plate
• Sold as a pair
• Gate needs to be drilled with 4 x 10mm Holes (24mm in from the side and 47 apart)
• Hinge panel needs to be drilled 4 x 14mm Holes (40mm in from the side and 60mm apart)
• For best results allow for a 16mm gap between the hinge panel and gate

Matt White Glass to Glass Spring Hinge

• Matt White Glass to Glass Gate Hinge
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Suits 8 & 10mm Glass Gates
• Suits 12mm Hinge Panel
• 316 Grade Stainless powder coated backing plate
• Sold as a pair
• Gate needs to be drilled with 4 x 10mm Holes (24mm in from the side and 47 apart)
• Hinge panel needs to be drilled 4 x 14mm Holes (40mm in from the side and 60mm apart)
• For best results allow for a 16mm gap between the hinge panel and gate

Polished Stainless Glass to Wall/Post Spring Hinge

• Polished Stainless Steel
• Glass to Wall/Square Post
• Use for Glass Pool Fence or Glass Balustrade Gate
• Suits 8 & 10mm Glass Gates
• 316 Grade Stainless
• Gate needs to be drilled with 4 x 10mm Holes (24mm in from the side and 47 apart)
• You will need to allow for a gap of 22mm between the gate and post

Satin Stainless Glass to Wall/Post Spring Hinge

• Glass to Wall/Square Post
• Use for Glass Pool Fence or Glass Balustrade Gate
• Suits 8 & 10mm Glass Gates
• 316 Grade Stainless
• Gate needs to be drilled with 4 x 10mm Holes (24mm in from the side and 47 apart)
• You will need to allow for a gap of 22mm between the gate and post

Matt Black Glass to Wall/Post Spring Hinge

• Matt Black
• Glass to Wall/Square Post
• Use for Glass Pool Fence or Glass Balustrade Gate
• Suits 8 & 10mm Glass Gates
• 316 Grade Stainless
• Gate needs to be drilled with 4 x 10mm Holes (24mm in from the side and 47 apart)
• You will need to allow for a gap of 22mm between the gate and post

Matt White Glass to Wall/Post Spring Hinge

• Matt White
• Glass to Wall/Square Post
• Use for Glass Pool Fence or Glass Balustrade Gate
• Suits 8 & 10mm Glass Gates
• 316 Grade Stainless
• Gate needs to be drilled with 4 x 10mm Holes (24mm in from the side and 47 apart)
• You will need to allow for a gap of 22mm between the gate and post

600 x 1200 x 12mm Economy Spring Hinge Panels

Glass Gate Spring Hinge Panel. Used to swing a glass gate off.

• Width: 600mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 22kg
• Holes: 4 x 14mm Holes to fix glass gate hinges

Install with Economy Glass Gate Panel and either glass to glass spring hinges or Polaris 155 series hinges.

Glass is certified to Australian Standards

Note: This panel will need to be secured to a post or another glass panel using Glass Braces or Glass Clamps. It will not hole a gate if only supported by Spigots.

800 x 1200 x 12mm Economy Spring Hinge Panels

Glass Gate Spring Hinge Panel. Used to swing a glass gate off.

• Width: 800mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 29kg
• Holes: 4 x 14mm Holes to fix glass gate hinges

Install with Economy Glass Gate Panel and either glass to glass spring hinges or Polaris 155 series hinges.

Glass is certified to Australian Standards

1000 x 1200 x 12mm Economy Spring Hinge Panels

Glass Gate Spring Hinge Panel. Used to swing a glass gate off.

• Width: 1000mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 36kg
• Holes: 4 x 14mm Holes to fix glass gate hinges

Install with Economy Glass Gate Panel and either glass to glass spring hinges or Polaris 155 series hinges.

Glass is certified to Australian Standards

1100 x 1200 x 12mm Economy Spring Hinge Panels

Glass Gate Spring Hinge Panel. Used to swing a glass gate off.

• Width: 1100mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 40kg
• Holes: 4 x 14mm Holes to fix glass gate hinges

Install with Ecomomy Glass Gate Panel and either glass to glass spring hinges or polaris 155 series hinges.

Glass is certified to Australian Standards

1200 x 1200 x 12mm Economy Spring Hinge Panels

Glass Gate Spring Hinge Panel. Used to swing a glass gate off.

• Width: 1200mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 43kg
• Holes: 4 x 14mm Holes to fix glass gate hinges

Install with Economy Glass Gate Panel and either glass to glass spring hinges or Polaris 155 series hinges.

Glass is certified to Australian Standards

1300 x 1200 x 12mm Economy Spring Hinge Panels

Glass Gate Spring Hinge Panel. Used to swing a glass gate off.

• Width: 1300mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 47kg
• Holes: 4 x 14mm Holes to fix glass gate hinges

Install with Economy Glass Gate Panel and either glass to glass spring hinges or Polaris 155 series hinges.

Glass is certified to Australian Standards

1400 x 1200 x 12mm Economy Spring Hinge Panels

Glass Gate Spring Hinge Panel. Used to swing a glass gate off.

• Width: 1400mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 50kg
• Holes: 4 x 14mm Holes to fix glass gate hinges

Install with Economy Glass Gate Panel and either glass to glass spring hinges or Polaris 155 series hinges.

Glass is certified to Australian Standards

1500 x 1200 x 12mm Economy Spring Hinge Panels

Glass Gate Spring Hinge Panel. Used to swing a glass gate off.

• Width: 1500mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 54kg
• Holes: 4 x 14mm Holes to fix glass gate hinges

Install with Economy Glass Gate Panel and either glass to glass spring hinges or Polaris 155 series hinges.

Glass is certified to Australian Standards

1600 x 1200 x 12mm Economy Spring Hinge Panels

Glass Gate Spring Hinge Panel. Used to swing a glass gate off.

• Width: 1600mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 58kg
• Holes: 4 x 14mm Holes to fix glass gate hinges

Install with Economy Glass Gate Panel and either glass to glass spring hinges or Polaris 155 series hinges.

Glass is certified to Australian Standards

1700 x 1200 x 12mm Economy Spring Hinge Panels

Glass Gate Spring Hinge Panel. Used to swing a glass gate off.

• Width: 1700mm
• Height: 1200mm
• Thickness: 12mm
• Weight: 61kg
• Holes: 4 x 14mm Holes to fix glass gate hinges

Install with Economy Glass Gate Panel and either glass to glass spring hinges or Polaris 155 series hinges.

Glass is certified to Australian Standards

Polished Stainless Glass to Glass Pool Fence Deluxe Latch

• Deluxe Polished Stainless Glass to Glass Latch - Straight Line
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Both Backing plates and latch are 316 Stainless Steel
• Requires Gate to be drilled (2 x 10mm Holes, 20mm in from edge and 42mm apart)
• Latch Panel must be 12mm - No holes required
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and latch panel

View Technical Drawings Here

View Installation Instructions Here

Satin Stainless Glass to Glass Pool Fence Deluxe Latch

• Deluxe Satin Stainless Glass to Glass Latch - Straight Line
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Both Backing plates and latch are 316 Stainless Steel
• Requires Gate to be drilled (2 x 10mm Holes, 20mm in from edge and 42mm apart)
• Latch Panel must be 12mm - No holes required
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and latch panel

View Technical Drawings Here

View Installation Instructions Here

Black Stainless Glass to Glass Pool Fence Deluxe Latch

• Deluxe Matt Black Glass to Glass Latch - Straight Line
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Both Backing plates and latch are 316 Stainless Steel
• Requires Gate to be drilled (2 x 10mm Holes, 20mm in from edge and 42mm apart)
• Latch Panel must be 12mm - No holes required
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and latch panel

View Technical Drawings Here

View Installation Instructions Here

White Stainless Glass to Glass Pool Fence Deluxe Latch

• Deluxe Matt White Glass to Glass Latch - Straight Line
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Both Backing plates and latch are 316 Stainless Steel
• Requires Gate to be drilled (2 x 10mm Holes, 20mm in from edge and 42mm apart)
• Latch Panel must be 12mm - No holes required
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and latch panel

View Technical Drawings Here

View Installation Instructions Here

Polished Stainless Glass to Wall Pool Fence Economy Latch

• Polished Stainless Glass to Wall/Square Post Latch
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Backing Plates 316 Stainless Steel
• Requires Gate to be drilled (2 x 12mm Holes, 20mm in from edge and 42mm apart)
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and Post/Wall

Polished Stainless Glass to Wall Pool Fence Deluxe Latch

• Glass to Wall/Square Post
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Backing Plates are powder coated 316 Stainless Steel
• Requires Gate to be drilled (2 x 12mm Holes, 20mm in from edge and 42mm apart)
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and Post/Wall

View Technical Drawings Here

View Installation Instructions Here

Satin Stainless Glass to Wall Pool Fence Economy Latch

• Satin Stainless Glass to Wall/Square Post Latch
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Backing Plates 316 Stainless Steel
• Requires Gate to be drilled (2 x 12mm Holes, 20mm in from edge and 42mm apart)
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and Post/Wall

Satin Stainless Glass to Wall Pool Fence Deluxe Latch

• Glass to Wall/Square Post
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Backing Plates 316 Stainless Steel
• Requires Gate to be drilled (2 x 12mm Holes, 20mm in from edge and 42mm apart)
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and Post/Wall

View Technical Drawings Here

View Installation Instructions Here

Black Stainless Glass to Wall Pool Fence Deluxe Latch

• Glass to Wall/Square Post
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Backing Plates are powder coated 316 Stainless Steel
• Requires Gate to be drilled (2 x 12mm Holes, 20mm in from edge and 42mm apart)
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and Post/Wall

View Technical Drawings Here

View Installation Instructions Here

Matt White Glass to Wall Pool Fence Latch

• Matt White Glass to Wall/Square Post
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Backing Plates are powder coated 316 Stainless Steel
• Requires Gate to be drilled (2 x 12mm Holes, 20mm in from edge and 42mm apart)
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and Post/Wall

White Stainless Glass to Wall Pool Fence Deluxe Latch

• Glass to Wall/Square Post
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Backing Plates are powder coated 316 Stainless Steel
• Requires Gate to be drilled (2 x 12mm Holes, 20mm in from edge and 42mm apart)
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and Post/Wall

View Technical Drawings Here

View Installation Instructions Here

Polished Stainless Glass to Glass 90 Degree External Latch

• Glass to Glass at a 90 Degree External Angle Latch
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Backing Plates are 316 Stainless Steel
• Requires Gate to be drilled (2 x 10mm Holes, 20mm in from edge and 42mm apart)
• Latch Panel must be 12mm - No holes required
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and latch panel

Satin Stainless Glass to Glass 90 Degree External Latch

• Glass to Glass at a 90 Degree External Angle Latch
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Backing Plates are 316 Stainless Steel
• Latch is Black Polymer
• Requires Gate to be drilled (2 x 10mm Holes, 20mm in from edge and 42mm apart)
• Latch Panel must be 12mm - No holes required
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and latch panel

Matt Black Glass to Glass 90 Degree External Latch

• Glass to Glass at a 90 Degree External Angle Latch
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Latch and Backing plates are Matt Black
• Requires Gate to be drilled (2 x 10mm Holes, 20mm in from edge and 42mm apart)
• Latch Panel must be 12mm - No holes required
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and latch panel

Matt White Glass to Glass 90 Degree External Latch

• Glass to Glass at a 90 Degree External Angle Latch
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Latch and Backing plates are Matt White
• Requires Gate to be drilled (2 x 10mm Holes, 20mm in from edge and 42mm apart)
• Latch Panel must be 12mm - No holes required
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and latch panel

Deluxe Double Friction Square Core Hole Spigot (Pool Fence Only)

• Pool Fence Square Core Hole Spigot
• Double Friction for easy tilt adjustment and alignment.
• Available in:
  • Mirror Polished Stainless Steel
  • Satin Polish Stainless Steel
  • Matt Black
• Includes terminal for quick and easy earthing if required

Made from superior strength duplex 2205 grade stainless steel, the Lifestyle square range provides the perfect mix of quality and strength. Innovatively designed recessed friction plates and patented double friction technology enables easy installation and till adjustment of glass panels.

Deluxe Polished Glass to Glass 90 Degree External Latch

• Glass to Glass at a 90 Degree External Angle Latch
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Latch and Backing plates are Polished Stainless Steel
• Requires Gate to be drilled (2 x 10mm Holes, 20mm in from edge and 42mm apart)
• Latch Panel must be 12mm - No holes required
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and latch panel

View Technical Drawings Here

View Installation Instructions Here

Deluxe Satin Glass to Glass 90 Degree External Latch

• Glass to Glass at a 90 Degree External Angle Latch
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Latch and Backing plates are Satin Stainless
• Requires Gate to be drilled (2 x 10mm Holes, 20mm in from edge and 42mm apart)
• Latch Panel must be 12mm - No holes required
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and latch panel

View Technical Drawings Here

View Installation Instructions Here

Deluxe Matt Black Glass to Glass 90 Degree External Latch

• Glass to Glass at a 90 Degree External Angle Latch
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Latch and Backing plates are Matt Black
• Requires Gate to be drilled (2 x 10mm Holes, 20mm in from edge and 42mm apart)
• Latch Panel must be 12mm - No holes required
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and latch panel

View Technical Drawings Here

View Installation Instructions Here

Deluxe Matt White Glass to Glass 90 Degree External Latch

• Glass to Glass at a 90 Degree External Angle Latch
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Latch and Backing plates are Matt White
• Requires Gate to be drilled (2 x 10mm Holes, 20mm in from edge and 42mm apart)
• Latch Panel must be 12mm - No holes required
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and latch panel

View Technical Drawings Here

View Installation Instructions Here

Polished Glass to Glass 90 Degree Internal Angle Pool Fence Gate Latch

• Glass to Glass at a 90 Degree Internal Angle Latch
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Backing Plates are Polished 316 Stainless Steel
• Latch is Black Polymer
• Requires Gate to be drilled (2 x 10mm Holes, 20mm in from edge and 42mm apart)
• Latch Panel must be 12mm - No holes required
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and latch panel

Deluxe Polished Glass to Glass 90 Degree Internal Angle Pool Fence Gate Latch

• Glass to Glass at a 90 Degree Internal Angle Latch
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Requires Gate to be drilled (2 x 10mm Holes, 20mm in from edge and 42mm apart)
• Latch Panel must be 12mm - No holes required
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and latch panel

View Technical Drawings Here

View Installation Instructions Here

Satin Glass to Glass 90 Degree Internal Angle Pool Fence Gate Latch

• Glass to Glass at a 90 Degree Internal Angle Latch
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Backing Plates are Satin Finish 316 Stainless Steel
• Latch is Black Polymer
• Requires Gate to be drilled (2 x 10mm Holes, 20mm in from edge and 42mm apart)
• Latch Panel must be 12mm - No holes required
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and latch panel

Deluxe Satin Glass to Glass 90 Degree Internal Angle Pool Fence Gate Latch

• Glass to Glass at a 90 Degree Internal Angle Latch
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Requires Gate to be drilled (2 x 10mm Holes, 20mm in from edge and 42mm apart)
• Latch Panel must be 12mm - No holes required
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and latch panel

View Technical Drawings Here

View Installation Instructions Here

Black Glass to Glass 90 Degree Internal Angle Pool Fence Gate Latch

• Glass to Glass at a 90 Degree Internal Angle Latch
• Use for Glass Pool Fence Gate or Glass Balustrade Gate
• Backing Plates are Black Powder Coated 316 Stainless Steel
• Latch is Black Polymer
• Requires Gate to be drilled (2 x 10mm Holes, 20mm in from edge and 42mm apart)
• Latch Panel must be 12mm - No holes required
• Suits 8, 10 and 12mm gates
• For best results leave a 9mm gap between the gate and latch panel
